HIoT Air Quality Monitor

Features

This device has the most advanced humidity, temperature, and air quality (PM2.5, PM10, CO₂, TVOC) sensors combined in a small and beautiful package. The device comes with Bluetooth and Wi-Fi connectivity to let you to configure it from your mobile app and then send the information to RTD HIoT Cloud. latest 1,000 measureing records (approx. 10 days)can be stored in RTD HIoT Cloud. A warning E-Mail/App notification will be send to you if any outstanding air quality is measured. If linked with Our HIoT Relay Switch Box, your home air conditioner/purifier can be switch on automatically/manually from mobile app after got this warning.

Application

At Home

Monitor the air quality conditions in real time to protect you, your family members and your pets. When you not in home or you are on sleeping at home, HIoT Air Quality Monitor will keep upload latest air quality information to HIoT Cloud. Then you can:

Check the air quality records of your home for past 10 days from your mobile phone or PC.
Set the alarm to notice you by E-Mail or Mobile App when air quality is outstanding.
Link the alarm to Our HIoT Relay Switch Box to control on the air conditioner/purifier to improve the air quality.

In Car

One of the great pleasures in driving is being able to drive with windows down (or even top down if you have a convertible) on the freeway this summer. But air quaity is one of the main concern. Even driving with windows up, Carbon Dioxide (CO₂) level in cabin also is another concern. High levels of CO₂ diminish cognitive abilities, reduce response times, and impair the ability for an individual to make strategic decisions. If you drive with HIoT Air Quality Monitor, you can:

Check the PM2.5 and PM10 level is now enough for you to windows down or top down. The concentrations of PM2.5 should not exceed 10 µg/m3 and 20 µg/m3 for PM10.
Check the CO₂ level in cabin. If the level is too high, it should replace new filters for the air conditioner of your car. The recommonded level of CO₂ is 1200–1300 ppm.

Plan your daily trip

Apart from money and time, healthy should be also onf of the concern when plan you way to home/work daily. The built-in battery of HIoT Air Quality Monitor can let it go with you and help you to monitor the air quality secretly. Then you can review the air quality data in mobile app weekly and plan a best way to home/work.

Your weekly exposure of PM2.5 and PM10 level should not exceed 10 µg/m3 and 20 µg/m3 respectively

Specification

Dimension : 98mm x98mm x32mm (LxWxH)
Operation Temperature : -10 ~ 50 ^oC
Operation Humidity : ≤95% RH(non-condensing)
Type of Built-in Battery : Li-ion Polymer 2500mAh (approx: 8hours continuous operation)
Charging Voltage : 5VDC
Cast material: ABS
Measurement
- CO₂ : 1ppm (Resolution) / 400~5000 ppm (Range) / +/- 25% (Accuracy)
- CH₂O : 1ug per m³ (Resolution) / 0~2000 ug per m³ (Range) / +/- 25% (Accuracy)
- TVOC: 1ug per m³ (Resolution) / 0~2000 ug per m³ (Range) / +/- 25% (Accuracy)
- PM2.5: 1ug per m³ (Resolution) / 0~999 ug per m³ (Range) / +/- 10% (Accuracy)
- PM10: 1ug per m³ (Resolution) / 0~1000 ug per m³ (Range) / +/- 10% (Accuracy)
- Temperature : 0.1 ^oC (Resolution) / -40~100 ^oC (Range) / +/- 0.5^oC (Accuracy)
- Humidity : 0.1%RH (Resolution) / 0~100%RH (Range) / +/- 3%RH (Accuracy)
